Yamaha WOLVERINE R-SPEC YXE70WPAJ User Manual

4-22
4
To install the tailgate
Place the tailgate in the original position, and
then hook the latches.
The tailgate can also be installed at the front
of the cargo bed. Install the tailgate and hook
the latches as shown.
EBU33614
Front shock absorbers
The shock absorber assemblies are equipped
with a spring preload adjusting nut, a rebound
damping force adjusting screw, a fast com-
pression damping force adjusting bolt, and a
slow compression damping force adjusting
screw.
1. Tailgate
2. Latch
2
2
1
1. Tailgate
2. Latch
2 2
1
UB3D7AE0.book Page 22 Tuesday, November 7, 2017 9:38 AM
