Controls and instruments
The vehicle you have purchased may differ slightly from those shown in the figures of this man-
ual.
15 14
3 4 5,6 72
13 1116 12
81 109
1. Light switch
2. On-Command drive knob
3. Steering wheel
4. Main switch
5. Helmet indicator light
6. Seat belt indicator light
7. Multi-function meter unit
8. Auxiliary DC jack
9. Passenger handhold
10.Glove compartment
11.Storage compartment
12.Drive select lever
13.Parking brake lever
14.Accelerator pedal
15.Brake pedal
16.Horn switch
