Yamaha WOLVERINE R-SPEC YXE70WPAJ User Manual

4-31
4
Slow compression damping force
To increase the slow compression damping
force and thereby harden the compression
damping, turn the slow compression damp-
ing force adjusting screw in direction (a). To
decrease the slow compression damping for-
ce and thereby soften the compression
damping, turn the adjusting screw in direction
(b).
1. Fast compression damping force adjusting bolt
Fast compression damping force settings:
Minimum (soft):
2 turn(s) out from the fully turned in posi-
tion
Standard:
1 1/4 turn(s) out from the fully turned in
position
Maximum (hard):
Adjusting bolt fully turned in
1
(a)
(b)
1. Slow compression damping force adjusting screw
1
(a)
(b)
UB3D7AE0.book Page 31 Tuesday, November 7, 2017 9:38 AM
