5-9
5
The tire pressure gauge is included as stan-
dard equipment. Make two measurements of
the tire pressure and use the second reading.
Dust or dirt in the gauge could cause the first
reading to be incorrect.
Tire wear limit
When the tire groove decreases to 3 mm
(0.12 in) due to wear, replace the tire.
Recommended tire pressure:
Vehicle load:
0 - maximum
Front:
75.0 kPa (0.750 kgf/cm², 11 psi)
Rear:
75.0 kPa (0.750 kgf/cm², 11 psi)
Minimum tire pressure:
Vehicle load:
0 - maximum
Front:
70.0 kPa (0.700 kgf/cm², 10 psi)
Rear:
70.0 kPa (0.700 kgf/cm², 10 psi)
Maximum vehicle load*:
327.0 kg (721 lb)
* Total weight of operator, passenger, acces-
sories, cargo, and (if applicable) trailer
tongue weight
1. Tire pressure gauge
UB3D7AE0.book Page 9 Tuesday, November 7, 2017 9:38 AM
