Yamaha XMAX - Page 105

10-1

4QFDJãDBUJPOT
%JNFOTJPOT
Overall length:
2185 mm (86.0 in)
Overall width:
775 mm (30.5 in)
Overall height:
1415/1465 mm (55.7/57.7 in)
Seat height:
795 mm (31.3 in)
Wheelbase:
1540 mm (60.6 in)
Ground clearance:
135 mm (5.31 in)
Minimum turning radius:
2.6 m (8.53 ft)
8FJHIU
Curb weight:
179 kg (395 lb)
&OHJOF
Combustion cycle:
4-stroke
Cooling system:
Liquid cooled
Valve train:
SOHC
Number of cylinders:
Single cylinder
Displacement:
249.8 cm³
Bore × stroke:
70.0 × 64.9 mm (2.76 × 2.56 in)
Compression ratio:
10.5 : 1
Starting system:
Electric starter
Lubrication system:
Wet sump
&OHJOFPJM
Recommended brand:
YAMALUBE
SAE viscosity grades:
10W-40
Recommended engine oil grade:
API service SG type or higher, JASO
standard MA or MB
Engine oil quantity:
Oil change:
1.50 L (1.59 US qt, 1.32 Imp.qt)
With oil lter removal:
1.60 L (1.69 US qt, 1.41 Imp.qt)
'JOBMUSBOTNJTTJPOPJM
Type:
Motor oil SAE 10W-30 type SE or higher or
Gear oil SAE 85W GL-3
Quantity:
0.20 L (0.21 US qt, 0.18 Imp.qt)
$PPMBOURVBOUJUZ
Coolant reservoir (up to the maximum level
mark):
0.18 L (0.19 US qt, 0.16 Imp.qt)
Radiator (including all routes):
1.10 L (1.16 US qt, 0.97 Imp.qt)
"JSã MUFS
Air lter element:
Oil-coated paper element
'VFM
Recommended fuel:
Regular unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity:
13 L (3.4 US gal, 2.9 Imp.gal)
Fuel reserve amount:
2.4 L (0.63 US gal, 0.53 Imp.gal)
'VFMJOKFDUJPO
Throttle body:
ID mark:
B741 00
4QBSLQMVHT
Manufacturer/model:
NGK/LMAR8A-9
Spark plug gap:
0.8–0.9 mm (0.031–0.035 in)
$MVUDI
Clutch type:
Dry, centrifugal, shoe
%SJWFUSBJO
Primary reduction ratio:
1.000
Final drive:
Belt
Secondary reduction ratio:
7.590 (48/18 x 37/13)
Transmission type:
V-belt automatic
$IBTTJT
Frame type:
Underbone
Caster angle:
26.5 °
