3. Takungan cecair brek belakang (halaman 8-23)
4. Speedometer (halaman 5-2)
5. Paparan pelbagai fungsi (halaman 5-3)
6. Tachometer (halaman 5-3)
7. Takungan cecair brek depan (halaman 8-23)
11. Suis utama (halaman 4-7)
12. Tambahan DC jack (halaman 5-26)
,FUFSBOHBO
1. Tuil brek belakang (m/s 5-12)
2. Suis kiri handel (m/s 5-10)
8. Suis kanan handel (m/s 5-10)
9.
Tuil brek depan (m/s 5-12)
10.
Cengkaman pendikit (m/s 8-19)
