*OTUSVNFOUBOEDPOUSPMGVODUJPOT
5-7

7CFMU SFQMBDFNFOU USJQNFUFS i7
#FMU5SJQw
The V-belt replacement tripmeter
shows the distance traveled since the
V-belt was last replaced.
The V-belt replacement indicator “V-
Belt” will ash every 20000 km (12000
mi) to indicate that the V-belt should be
replaced.
After replacing the V-belt, reset the V-
belt replacement indicator and the V-
belt replacement tripmeter. To reset
them both, select the V-belt replace-
ment tripmeter, and then push the
“TRIP” switch for three seconds.
While the V-belt replacement tripmet
er
is ashing, push the “TRIP” switch for
15 to 20 seconds. Release the “TRIP”
switch, and the V-belt trip value will re-
set to zero.
5*1
If the V-belt is replaced before the V-
belt replacement indicator comes on
(i.e., before the periodic V-belt replace-
ment interval has been reached), the V-
belt replacement tripmeter must be re-
set for the V-belt replacement indicator
to come on at the correct time.
1. V-belt replacement indicator “V-Belt”
2. V-belt replacement tripmeter
1
2
*OGPSNBUJPOEJTQMBZ
The information display is equipped
with the following:
air temperature display
battery voltage display
traction control system display
average fuel consumption display
instantaneous fuel consumption
display
average speed display
warning message function
/BWJHBUJOHUIFJOGPSNBUJPOEJTQMBZ
Push the “INFO” switch to change the
display between the air temperature
display “Air-temp”, battery voltage dis-
play “Battery”, traction control system
display “TCS ON” or “TCSOFF”, aver-
age fuel consumption display “Con-
sumption/Average_ _._ km/L” or
“Consumption/Average_ _._ L/100
km”, instantaneous fuel consumption
display “Consumption_ _._ km/L” or
“Consumption_ _._ L/100 km” and av-
erage speed display “Average” in the
following order:
Air-temp
Battery TCS ON or TC-
SOFF
Consumption/Average_ _._
km/L
Consumption/Average_ _._
L/100 km
Consumption_ _._ km/L
Consumption_ _._ L/100 km Av-
erage
Air-temp
1. Information display
1
