Yamaha XVS650A - AIR INDUCTION SYSTEM; Air Induction System Installation Parts

–24–
Order Job/Part Q’ty Remarks
9
10
11
12
13
14
15
16
17
18
19
Cover
Cover
Vacuum hose 1
Air cut valve
Plug
Air cut valve to air cleaner hose
Air cleaner
Air Cleaner case
Bend hose
Air cut valve to reed valve hose
Reed valve
1
1
1
1
1
1
1
1
1
1
1
For installation, reverse the removal
procedure.
4 Nm (0.4 mkg)
2 Nm (0.2 mkg)
AIR INDUCTION SYSTEM
CARB
