HANDLEBAR
4-31
EAS1SL1161
HANDLEBAR
Removing the handlber
Order Part name Q’ty Remarks
Number plate Remove the band only.
1 Clutch cable 1 Disconnect.
2 Clutch lever holder 1
3 Engine stop switch 1
4 Brake master cylinder 1
5 Throttle cable cap 1
6 Throttle cable (pull) 1 Disconnect.
7 Throttle cable (return) 1 Disconnect.
8 Right grip 1
9 Tube guide 1
10 Collars 1
11 Left grip 1
12 Handlebar upper holder 2
13 Handlebar 1
14 Handlebar lower holder 2
15 Damper 4
To Next Page
