TIGHTENING TORQUES
2-14
EAS1SL1057
ENGINE TIGHTENING TORQUES
TIP
- marked portion shall be checked for torque tightening after break-in or before each race.
ITEM
Thread
size
Q’ty TIGHTENING TORQUES Remarks
Camshaft cap bolt M6 8 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Cylinder head blind plug M12 1 28 Nm (2.8 m·kgf, 20 ft·lbf)
Spark plug M10 1 13 Nm (1.3 m·kgf, 9.4 ft·lbf)
Cylinder head stud bolt (exhaust
pipe)
M6 3 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Cylinder head bolts M9 4 See TIP.
*1
Cylinder head bolts M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Cylinder head cover bolt M6 3 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Oil passage plug (cylinder head) M8 1 15 Nm (1.5 m·kgf, 11 ft·lbf)
Cylinder bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Oil pressure check bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Balancer weight plate screw M6 3 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Balancer driven gear nut M14 1 50 Nm (5.0 m·kgf, 36 ft·lbf)
Use a
lock
washer.
Balancer nut M10 1 45 Nm (4.5 m·kgf, 33 ft·lbf)
Use a
lock
washer.
Timing chain guide stopper plate
(exhaust side)
M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Timing chain tensioner cap bolt M6 1 6 Nm (0.6 m·kgf, 4.3 ft·lbf)
Timing chain tensioner bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Coolant drain bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Radiator hose clamp screw M6 8 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Radiator bolt M6 4 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Radiator pipe bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Radiator pipe joint bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Water pump housing cover bolt M6 4 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Oil pump bolt M5 2 5 Nm (0.5 m·kgf, 3.6 ft·lbf)
Oil pump cover screw M4 1 2.0 Nm (0.20 m·kgf, 1.4 ft·lbf)
Oil strainer bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Oil passage cover bolt (left crank-
case)
M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Throttle cable cover bolt M5 1 3.5 Nm (0.35 m·kgf, 2.5 ft·lbf)
Throttle body joint bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Throttle body joint clamp bolt M5 1 3.0 Nm (0.30 m·kgf, 2.2 ft·lbf)
Air filter joint clamp bolt M4 1 3.5 Nm (0.35 m·kgf, 2.5 ft·lbf)
Air filter case bolt M6 3 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
LT
M
LT
LT
LT
