TIGHTENING TORQUES
2-16
Drive sprocket nut M20 1 75 Nm (7.5 m·kgf, 54 ft·lbf)
Use a
lock
washer.
Drive axle oil seal stopper bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Segment M8 1 30 Nm (3.0 m·kgf, 22 ft·lbf)
Shift guide bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Stopper lever bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Shift pedal bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Rotor nut M12 1 65 Nm (6.5 m·kgf, 47 ft·lbf)
Stator screw M5 3 8 Nm (0.8 m·kgf, 5.8 ft·lbf)
Crankshaft position sensor bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
AC magneto lead holder bolt M5 1 8 Nm (0.8 m·kgf, 5.8 ft·lbf)
Coolant temperature sensor M10 1 16 Nm (1.6 m·kgf, 12 ft·lbf)
Neutral switch bolt M5 2 3.5 Nm (0.35 m·kgf, 2.5 ft·lbf)
Intake air temperature sensor screw M5 1 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Rectifier/regulator bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
ECU bolt M5 2 3.8 Nm (0.38 m·kgf, 2.8 ft·lbf)
Ignition coil bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Throttle position sensor screw M5 2 3.4 Nm (0.34 m·kgf, 2.5 ft·lbf)
Intake air pressure sensor screw M6 1 5 Nm (0.5 m·kgf, 3.6 ft·lbf)
ITEM
Thread
size
Q’ty TIGHTENING TORQUES Remarks
