Yamaha YZF-R1 Service Manual

– 1 –
1 Engine Specifications
Spec SBK STKSTD
Displacement 998 cm³ 998 cm³ 998 cm³
Bore/Stroke 78.0 x 52.2 mm 78.0 x 52.5 mm 78.0 x 52.2 mm
Maximum engine speed
(limiter controlled speed)
13800 rpm 13800 rpm 13800 rpm
Compression ratio
(recommended value)
13.7:1
(Depend of
head-gasket
and head
cylinder
thickness and
cylinder head
surface
grinding)
12.9:1
(Depending on
the thickness of
the head
gasket)
12.7:1
Valve timing (event angle) INT. 108°103°105°
EXT. 110°103°105°
Squish height (minimum) 0.65 mm 0.
65 mm 0.75 mm
Clearance between valve
and piston (minimum)
INT. 0.9 mm
(ATDC10°)
1.0 mm
(ATDC10°)
1.3 mm
(ATDC10°)
EXT. 1.8 mm
(BTDC10°)
2.5 mm
(BTDC10°)
2.8 mm
(BTDC10°)
Valve (tappet) clearance INT. 0.17 – 0.23 mm 0.11 – 0.20 mm 0.11 – 0.20 mm
EXT. 0.27 – 0.33 mm 0.21 – 0.25 mm 0.
21 – 0.25 mm

Yamaha YZF-R1 Specifications

General

Bore x Stroke	79.0mm x 50.9mm
Compression Ratio	13.0:1
Fuel System	Fuel injection with YCC-T and YCC-I
Final Drive	Chain
Front Tire	120/70ZR17
Rear Tire	190/55ZR17
Wheelbase	55.3 in
Fuel Capacity	4.5 gal
Curb Weight	448 lb
Width	27.2 in
Ground Clearance	5.1 in
Engine Type	Liquid-cooled inline 4-cylinder; DOHC, 4 valves per cylinder
Transmission	6-speed
Clutch	Multiplate slipper clutch
Front Suspension	43mm KYB® inverted fork; fully adjustable
Rear Suspension	KYB® single shock; fully adjustable
Front Brakes	Dual 320mm hydraulic disc; ABS
Rear Brakes	220mm hydraulic disc; ABS
