ENGINE OPERATION
28
8LV Series Operation Manual
STARTING THE ENGINE
(START UP)
1. Open the seacock.
2. Open the fuel tank cock.
3. Turn the battery switch on for engine and VCS.
4. Press the Power switch on the switch panel of
the selected station (1, Figure 1).
• The switch panel lamp will come on, and the
control head (Figure 2) “SEL” lamp (Figure 3)
will come on or flash.
• To use the Engine START/STOP switch, be
sure to turn the Power switch ON.
5. Press the control head “SEL” switch.
• Wait until the display shows the engine data.
The display is shown.
6. If engine start owner ID has been set, enter the
password into the display.
• Engine start owner ID has been set, the engine
can be started in 10 seconds after entering the
password into the display.
7. Move the control head handle to the N (Neutral)
position.
8. For stern drives, check that it is not aligned with
the trailer position.
9. Press the Engine START/STOP switch
(2, Figure 1) and power on the starter.
• When the engine starts, the VCS display will
show the screen with engine conditions
(Figure 4).
Note:
1. Concerning the control head “SEL” lamp.
For Multi-Station: the “SEL” lamp will flash and
for Single Station: the “SEL” lamp will come on.
2. Pressing the Engine START/STOP switch when
the “SEL” lamp is flashing allows the station to
be selected as the engine is started.
3. The engine will not start or stop if the Power
switch is OFF. The Power switch must be ON at
all times when the engine is running.
4. Do not press the engine START/STOP switch
except for stopping the engine.
5. If the stern drive is in the trailer position, the
buzzer sounds and the engine does not start.
Figure 1
Figure 2
Figure 3
Figure 4
SEL
NEUTRAL
PORT
STBO
NTRL
SYNC
TROL
037639-00E00
Neutral
Control head panel
037638-00X00
037635-00X00
