Tightening Fasteners
Use the correct amount of torque when you tighten fasteners on the machine. Applying excessive torque
may damage the fastener or component and not enough torque may cause a leak or component failure.
■ Main Bolt and Nut Tightening Torque
No. Tightening Parts
Thread
Dia. × Pitch
Material Lubricant
Tightening Torque
N·m (kgf-m)
1 Exhaust Manifold M10 × 1.25 S45C – 36 ± 4 (3.7 ± 0.4)
2 Mounting Foot M12 × 1.25 SCM435 – 80 ± 10 (8.2 ± 1.0)
3
Union, Lubricating Oil
Filter
3/4 - 16 UNF Apply lubricating oil 43.1 (4.4)
4 Lubricating Oil Filter 3/4 - 16 UNF Apply lubricating oil 14.7 - 19.6 (1.5 - 2.0)
5
Bolts, Installation of
Seawater Pump
M8 × 1.25 S45C – 20 ± 3 (2.0 ± 0.3)
6
Support, Lubricating
Pipe (Lubricating Oil
Filter in/out)
M8 × 1.25 S45C – 5 ± 1 (0.5 ± 0.1)
7 Nut, Starter B Terminal M8 × 1.25 S45C – 21 ± 2 (2.1 ± 0.2)
8
Bracket, EDU (Head
Cover Insert of Resin)
M6 × 1 S45C – 10 ± 1 (1.0 ± 0.1)
9
Battery Terminal (Head
Cover Insert of Resin)
M6 × 1 S45C – 10 ± 1 (1.0 ± 0.1)
10 Nut, Battery Terminal M8 × 1.25 – 10 ± 1 (1.0 ± 0.1)
11
V Band, Turbo-charger
and Mixing Elbow
Apply Molybdenum
Coat on the threads
After tightening at 6 ± 1 (0.6 ±
0.1), hit the outer circumference
with a plastic hammer (3 times
evenly at 3 places or more), and
retighten at 6 ± 1 (0.6 ± 0.1).
12
Bolts, Installation of
Vibration Isolator
M16 × 2 SMC435 – 196 ± 10 (20.0 ± 1.0)
