Yanmar SD25 - Fitting a Fixed Propeller (2-Blade)

BEFORE YOU OPERATE
SD25 Operation Manual 17
12/05
Fitting a Fixed Propeller (2-Blade)
1–Spacer
2–Grease
3 – Propeller
4–Washer
5–Nut *
6–Bolt **
Figure 1
■ Locking procedure for fixed propeller nut (optional)
When tightening the nut to 60 to 70 N·m (44 to 52 lb-ft) torque for the SD25, move the shift
lever to ahead and hold the crankshaft V-pulley clamp nut with a wrench to stop the
propeller rotating.
1
2
3
4
5
6
K0005446
Size Tightening torque
* M16 60 to 70 N·m (44 to 52 lb-ft)
** M8  75 mm 11 to 15 N·m (8 to 11 lb-ft)
