Yardistry YM11915 - Step 26: Attach Twist Brackets

62 support@yardistrystructures.com
A: Measure 4-3/8” down from the inside of each Post Assembly on the long side of the unit, place bottom of either
45° Twist Bracket LT or 45° Twist Bracket RT at measured location then attach to Post Assembly and Corner
Rafter (Left or Right) with three #12 x 1-1/2” Pan Screws per bracket. (F26.1 and F26.2)
Step 26: Attach Twist Brackets
Components:
2 x 45° Twist Bracket LT
2 x 45° Twist Bracket RT
45° Twist
Bracket
(LT/RT)
#12 x 1-1/2”
Pan Screw
Post
Assembly
Hardware
12 x #12 x 1-1/2” Pan Screw
F26.1
4-3/8”
F26.2
Rafter Corner
(Left or Right)
Post
Assembly
Post
Assembly
