YASKAWA A1000 Series Installation Manual

YASK AWA E LEC TR IC TOBP C730600 38C 1000-Series Option AI-A3 Installation Manual 3
Table of Contents
1 PREFACE AND SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 RECEIVING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 OPTION COMPONENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5 INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . .10
6 RELATED PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . .22
7 TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
8 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
