5.2 Drive Derating
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
91
Model
Rated Current (A)
Heavy Duty Rating (HD)
Parameter C6-01 = 0
Normal Duty Rating (ND)
Parameter C6-01 = 1
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
5242 192 84 - - - 242 84 - - -
5289 242 148 - - - 289 148 - - -
■ 6-Phase/12-Pulse 400 V Class
Table 5.13 Carrier Frequency and Rated Current Derating When A1-02 = 0, 1, 2, 3, 5, 7, 8 (< 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD)
C6-01 = 0
Normal Duty Rating (ND)
C6-01 = 1
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
T103 91.0 91.0 91.0 80.6 67.6 54.6 103 103.0 90.3 80.1 67.3 55
T140 112.0 112.0 91.8 78.4 - - 140 122.8 96.7 79 - -
T168 150.0 150.0 123.0 105.0 - - 168 150.5 124.4 107 - -
T208 180.0 180.0 147.6 126.0 - - 208 179.7 137.2 109 - -
T250 216.0 216.0 177.1 151.2 - - 250 221.8 179.4 151 - -
T302 260.0 260.0 213.2 182.0 - - 302 268.8 218.9 186 - -
T371 304.0 304.0 249.3 212.8 - - 371 327.2 261.6 218 - -
T414 371.0 371.0 304.2 259.7 - - 414 371 304.7 261 - -
T477 414.0 345.7 - - - - 477 367 - - - -
T568 477.0 398.3 - - - - 568 437 - - - -
T605 605.0 505.2 - - - - 675 529 - - - -
T720 605.0 505.2 - - - - 720 564 - - - -
Table 5.14 Carrier Frequency and Rated Current Derating When A1-02 = 4 [AOLV] (< 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD)
C6-01 = 0
Normal Duty Rating (ND)
C6-01 = 1
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
T103
91.0 91.0 70.2 54.6 35.1 103 92.8 69.9 54.6 35.5
T140
112.0 95.2 65.0 44.8 - 140 101.1 62.0 36 -
T168
150.0 127.5 87.0 60.0 - 168 128.7 89.5 63 -
T208
180.0 153.0 104.4 72.0 - 208 144.3 80.6 38 -
T250
216.0 183.6 125.3 86.4 - 250 186.5 123.0 81 -
T302
260.0 221.0 150.8 104.0 - 302 227.2 152.5 103 -
T371
304.0 258.4 176.3 121.6 - 371 272.5 174.0 108 -
T414
371.0 315.4 215.2 148.4 - 414 316 216.9 151 -
T477
414.0 259.8 - - - 477 230 - - -
T568
477.0 299.3 - - - 568 274 - - -
T605
605.0 379.6 - - - 675 345 - - -
T720
605.0 379.6 - - - 720 368 - - -

YASKAWA GA800 GA80U Series Specifications

General

Series	GA800 GA80U Series
Output Voltage	Matches Input Voltage
Power Range	0.4kW to 1.5MW
Power Rating	0.4 kW to 450 kW
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Cooling Method	Air Cooled
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Ethernet, Modbus, DeviceNet, Profibus, CC-Link
Safety	STO (Safe Torque Off)
Operating Temperature	+50°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20, IP00
