7.3 CPU Unit
7-9
7.3.2 Units and Circuit Boards in the CPU Unit
" Control Circuit Board (JANCD-NCP01)
This board performs to control the entire system, display to the programming pendant, control
the operating keys, control operation, calculate motion type. This board has the Serial inter-
face for RS-232C, video output, PS2 connector, and LAN (100BASE-TX/10BASE-T). But this
board, however, cannot be used for video output and PS connector. (The video output and the
PS connector must be adjusted by the manufacturer only.)
" Control Power Supply (CPS-420F)
This unit supplies the DC power (DC5V, DC24V, DC3.3V, DC±12V) for control (system, I/O,
brake). It is also equipped with the input function for turning the control power supply on and
off.
Items Specifications
Input
Rating Input Voltage: 200/220VAC
Voltage Fluctuation Range: +10% to -15% (170 to 242VAC)
Frequency: 50/60Hz ± 2Hz (48 to 62Hz)
Output Voltage
DC + 5V : 20A
DC +24V : 12A (24V1: 4A, 24V2: 3.5A, 24V3: 4.5A)
DC +3.3V : 12A
DC +12V : 1.5A
DC -12V : 0.5A
Indicator
DISPLAY Color Status
SOURCE Green Lights when AC power supply input
(Normally ON)
POWER
ON
Green Lights when DC power supply output
(Normally ON)
+5V Red Lights when +5V output error
(ON when abnormal)
+24V Red Lights when +24V output error
(ON when abnormal)
OTHER Red Lights when +3.3V, ±12V output error
(Lights if error occurs)
FAN Red Lights if a fan-related errors in the con-
trol power supply unit. (Lights if error
occurs)
OHT Red Lights when units interior overheats
(ON when abnormal)
Detection temperature: About 65°C
