Yealink SIP-T19P User Manual

Basic Call Features
67
1. Press the OK soft key, the phone returns to the idle screen and call completion is
activated.
When the called party becomes idle, the following prompt appears on the LCD
screen of the phone:
2. Press the OK soft key to redial the number.
Note
You can press a call return key to place a call back to the last incoming call.
To configure a call return key via web user interface:
1. Click on DSSKey->Programmable Key.
2. Select the desired programmable key.
3. Select Call Return from the pull-down list of Type.
4. Click Confirm to accept the change.
Note
Call completion is not available on all servers. For more information, contact your system
administrator.
A call return key is configurable via web user interface only.

Yealink SIP-T19P Specifications

General

Speakerphone	Yes
Voice codecs	CNG, G.711, G.723, G.726, G.729ab, VAD
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Front camera	No
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Security algorithms	802.1x RADIUS, AES, HTTPS
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	IPv6
Ethernet LAN (RJ-45) ports	2
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	185 mm
Height	143 mm
