Yealink SIP-T19P User Manual

User Guide for the SIP-T19P IP Phone
38
6. (Optional.) Select the contact information you want to import into the local directory
from the pull down list of Index.
7. Click Import to complete importing the contact list.
To export contact list via web user interface:
1. Click on Directory->Local Directory.
2. Click Export XML (or Export CSV).
3. Click Save to save the contact list to your local system.
Note
The built-in phone directory can store names and numbers for a blacklist. You can store
up to 30 contacts in your phone’s blacklist; add, edit, delete or search for a contact in
the blacklist; even dial a contact number from the blacklist, but any incoming call from
the blacklist will be rejected automatically.
To add a contact to the blacklist manually:
1. Press Menu->Dir->Blacklist.
2. Press the Add soft key.
Importing/exporting contact lists are configurable via web user interface only.

Yealink SIP-T19P Specifications

General

Speakerphone	Yes
Voice codecs	CNG, G.711, G.723, G.726, G.729ab, VAD
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Front camera	No
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Security algorithms	802.1x RADIUS, AES, HTTPS
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	IPv6
Ethernet LAN (RJ-45) ports	2
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	185 mm
Height	143 mm
