Yealink SIP-T22P User Manual

Troubleshooting
125
How to export system log?
We may need you to provide a system log to help analyze your problem.
To export a system log via web user interface:
1. Click on Settings->Configuration.
2. Select 6 from the pull-down list of System Log Level.
3. Click Confirm to accept the change.
The web user interface prompts “Do you want to restart your machine?”. The
configuration will take effect after reboot.
4. Click OK to reboot the phone.
After rebooting the phone, the system log level is set as 6, the debug level.
5. Mark the Local radio box in the Export System Log field.
6. Click Export to open file download window, and then save the file to your local
system.
You can also export the system log to a syslog server. Contact your system administrator
for more information.
Note
How to export/import phone configurations?
We may need you to provide the phone configurations to help analyze your problem. In
some instance, you may need to import configurations to the phone.
To export the phone configurations via web user interface:
1. Click on Settings->Configuration.
It is recommended you reset the sytem log level to 3 after having the syslog file provided.

Yealink SIP-T22P Specifications

General

DC-in jack	Yes
Expansion module support	No
Ethernet LAN (RJ-45) ports	2
Volume control	Digital
Keypad number of keys	32
Number of handles included	1 pc(s)
Power requirements	100 - 240 VAC, 5 VDC
Power consumption (typical)	2.6 W
Power consumption (PowerSave)	1.5 W
Voice codecs	G.722, G.723, G.726
Touchscreen	-
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	300 entries
Number of VoIP accounts	3
Security algorithms	HTTPS, SRTP
Flash memory	8 MB
Internal memory	32 MB
Password protection type	User
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black

Weight and Dimensions

Depth	200 mm
Width	185 mm
Height	90 mm
Weight	770 g
