Yealink SIP-T22P User Manual

Customizing Your Phone
27
4. Select the desired ring tone from the pull-down list of Ring Type.
If Common is selected, this account will use the ring tone selected for the phone.
Refer to the above instruction.
5. Click Confirm to accept the change.
Note
To upload a custom ring tone for your phone via web user interface:
1. Click on Settings->Preference.
2. Click Browse to locate a ring tone file (file format must be *.wav) from your local
system.
A ring tone for the account is configurable via web user interface only.
The ring tone for an incoming call on the phone may be different. For example, when the
phone receives an incoming call from a contact stored in the local directory, it will play
the ring tone assigned to the contact in the contact directory (refer to Adding Contacts).
If no ring tone is assigned to the contact, the phone will play the ring tone assigned to the
associated group (refer to Adding Groups). Otherwise,the phone will play the ring tone
assigned to the account. If no ring tone is assigned to the account, the phone will play the
ring tone assigned for the phone.

Yealink SIP-T22P Specifications

General

DC-in jack	Yes
Expansion module support	No
Ethernet LAN (RJ-45) ports	2
Volume control	Digital
Keypad number of keys	32
Number of handles included	1 pc(s)
Power requirements	100 - 240 VAC, 5 VDC
Power consumption (typical)	2.6 W
Power consumption (PowerSave)	1.5 W
Voice codecs	G.722, G.723, G.726
Touchscreen	-
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	300 entries
Number of VoIP accounts	3
Security algorithms	HTTPS, SRTP
Flash memory	8 MB
Internal memory	32 MB
Password protection type	User
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black

Weight and Dimensions

Depth	200 mm
Width	185 mm
Height	90 mm
Weight	770 g
