Yealink SIP-T22P User Manual

Customizing Your Phone
37
4. To remove a list from the Enabled column, select the desired list and then click .
5. To adjust the display order of search results, select the desired list and then click
or .
The LCD screen displays the search results in the adjusted order.
6. Click Confirm to accept the change.
Note
To search for a contact in the enabled search source lists:
1. Pick up the handset, press the speakerphone or press the line key.
2. Enter a few continuous characters of the contact name or the contact phone number
using the keypad.
The contacts in the enabled search source lists whose name or phone number
matches the characters entered will appear on the LCD screen. You can press
or to scroll to the desired contact and then place a call to the contact.
Search source list in dialing is configurable via web user interface only.

Yealink SIP-T22P Specifications

General

DC-in jack	Yes
Expansion module support	No
Ethernet LAN (RJ-45) ports	2
Volume control	Digital
Keypad number of keys	32
Number of handles included	1 pc(s)
Power requirements	100 - 240 VAC, 5 VDC
Power consumption (typical)	2.6 W
Power consumption (PowerSave)	1.5 W
Voice codecs	G.722, G.723, G.726
Touchscreen	-
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	300 entries
Number of VoIP accounts	3
Security algorithms	HTTPS, SRTP
Flash memory	8 MB
Internal memory	32 MB
Password protection type	User
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black

Weight and Dimensions

Depth	200 mm
Width	185 mm
Height	90 mm
Weight	770 g
