Yealink SIP-T23G User Manual

User Guide for the SIP-T23P/G IP Phone
110
To perform a semi-attended transfer:
1. Press or the Tran soft key during a call.
2. Do one of the following:
- Enter the number you want to transfer the call to.
- Press the Dir soft key, and then select Local Directory. Select the desired group
and search for the contact (Directory should be configured in advance. Refer to
Directory on page 46 for more information).
- Press the Dir soft key, and then select History. Select the desired list and then
press or to select the entry (Directory should be configured in
advance. Refer to Directory on page 46 for more information).
- Press the Dir soft key, and then select Remote Phone Book. Select the desired
group and search for the contact (Directory should be configured in advance.
Refer to Directory on page 46 and Remote Phone Book on page 59 for more
information).
3. Press or to dial out.
4. Press or the Tran soft key to complete the transfer when receiving ringback.
To perform an attended transfer:
1. Press or the Tran soft key during a call.
2. Do one of the following:
- Enter the number you want to transfer the call to.
- Press the Dir soft key, and then select Local Directory. Select the desired group
and search for the contact (Directory should be configured in advance. Refer to
Directory on page 46 for more information).
- Press the Dir soft key, and then select History. Select the desired list and then
press or to select the entry (Directory should be configured in
advance. Refer to Directory on page 46 for more information).
- Press the Dir soft key, and then select Remote Phone Book. Select the desired
group and search for the contact (Directory should be configured in advance.
Refer to Directory on page 46 and Remote Phone Book on page 59 for more
information).
3. Press or to dial out.
4. After the party answers the call, press or the Tran soft key to complete the
transfer.
If you are using a handset, the transfer can be completed by hanging up the handset.
You can cancel the transfer before the call is connected by pressing the Cancel soft key.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
