Yealink SIP-T23G User Manual

Customizing Your Phone
47
6. Click Confirm to accept the change.
Note
To check the directory via phone user interface:
1. Press the Dir soft key when the phone is idle.
The LCD screen displays the enabled list(s) in the directory.
If there is only one list in the directory, press the Dir soft key to enter this list directly.
Note
The built-in phone directory can store the names and phone numbers of your contacts.
You can store up to 1000 contacts and 48 groups in your phone's local directory. You can
add new groups and contacts, edit, delete or search for a contact, or simply dial a
contact number from the local directory.
To add a group to the local directory:
1. Press the Dir soft key.
The IP phone enters the local directory directly as there is only Local Directory
enabled in the directory by default.
Directory is configurable via web user interface only.
If the remote phone book and LDAP are not configured in advance, you cannot see
remote phone book and LDAP lists on the phone user interface. For more information on
remote phone book, refer to Remote Phone Book on page 59. For more information on
the LDAP, refer to
Yealink_SIP-T2_Series_T19(P) E2_T4_Series_CP860_IP_Phones_Administrator_Guide .

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
