Yealink SIP-T23G User Manual

Advanced Phone Features
121
This chapter provides operating instructions for the advanced features of the SIP-T23P/G
IP phone. Topics include:
 Busy Lamp Field (BLF)
 BLF List
 Call Recording
 Hot Desking
 Intercom
 Multicast Paging
 Music on Hold
 Automatic Call Distribution (ACD)
 Shared Call Appearance (SCA)
 Bridged Line Appearance (BLA)
 Messages
If you require additional information or assistance with your new phone, contact your
system administrator.
You can use BLF to monitor a specific line for status changes on the phone. For example,
you can configure a BLF key on the phone to monitor the status of a friend’s line (busy or
idle). The BLF key LED illuminates solid red when the friend's line is in use. For more
information on BLF key LED indicators, refer to LED Instructions on page 14.
You can press a BLF key to dial out the monitored phone number when the monitored
line is idle. You can receive a visual or/and an audio alert (if enabled), and also pick up
calls that are received on the monitored line. For more information, contact your system
administrator.
To configure a BLF key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
