Yealink SIP-T23G User Manual

User Guide for the SIP-T23P/G IP Phone
126
To configure a URL record key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select URL Record from the Type field.
4. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
5. Enter the URL (e.g., http://10.1.2.224/phonerecording.cgi) in the Value field.
6. Press the Save soft key to accept the change or the Back soft key to cancel.
Record and URL record keys are configurable via web user interface at the path
DSSKey->Line Key.
The Record and URL Record keys control the recording function, and are available:
 During an active call
 When calls are on hold or mute
 During a blind or attended transfer
 During a conference call
 When the phone prompts you to answer an incoming call
The Record and URL Record keys are not available when:
 There are no connected calls on your phone
 You place a new call
To record a call:
1. Press the Record or URL Record key during a call.
If the recording starts successfully, the recording icon will appear on the LCD screen
and the Record or URL Record key LED will flash green.
2. Press the Record or URL Record key again to stop recording.
The recording icon disappears from the LCD screen and the Record or URL Record
key LED goes out.
Recording status indicators you need to know:
Circumstance
Icons on the LCD screen
A recording is started
appears on the LCD screen

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
