Yealink SIP-T23G User Manual

Customizing Your Phone
67
monitored status when the line keys are assigned with particular features, such as BLF.
The default key type of each line key is Line.
To assign functionality to a line key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key, and then press the Enter soft key.
3. Select the desired key type from the Type field.
4. (Optional.) Select the desired key event type from the Key Type field.
5. (Optional.) Select the desired line from the Account ID field.
6. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
7. (Optional.) Enter the corresponding value in the Value field.
8. (Optional.) Enter the corresponding value in the Extension field.
9. Press the Save soft key to accept the change or the Back soft key to cancel.
Line key is configurable via web user interface at the path DSSKey->Line Key.
Note
Line key features are explained in the following subchapters in detail:
 Line
 Speed Dial
 Voice Mail
 Direct Pickup
 Group Pickup
 DTMF
 Prefix
 Local Group
 XML Group
 XML Browser
 LDAP
 Conference
 Forward
 Transfer
 Hold
 DND
 SMS
 Group Listening
When the phone is idle, you can also long press the line key to configure it directly on the
phone.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
