Yealink SIP-T40G Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 71 OF 150
Figure 41 Configure Advanced Options
5.2.5.2.2.1.3 Configure Device Management Options
Configure the device profile type Device Management Options as directed in the following
table. These are common settings, which apply to all devices enabled for Device
Management.
Parameters not identified in the following table can usually be left with their default values.
Parameter Value Description
Device Configuration
Tags
Use Default System Tag Set Only
Allow Identity/Device
Profiles to Configure
Custom Tags
Checked Optional
Allow Groups to
Configure Custom
Tags
Checked Optional
Device Access
Protocol
http
Device Access FQDN <BroadWorks-XSP-Cluster-
Address>
Example: xsp.iop1.broadworks.net
If using an Xtended Services
Platform farm, set this to the
Xtended Services Platform cluster
FQDN. Otherwise, set it to the
individual Xtended Services
Platform FQDN or IP address.
Device Access Port <BroadWorks-XSP-Port>
Example: 80
This should be set to “80”.
Device Access
Context Name
dms This does not need to be defined.
BroadWorks defaults to the
system-defined value.
Device Access URI def This defines the directory the
Xtended Services Platform uses to
access the default configuration
files.

Yealink SIP-T40G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Wi-Fi	No
Security algorithms	AES, HTTPS, SSL/TLS
Networking standards	IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Voice codecs	G.711, G.711a, G.711u, G.722, G.726, G.729ab
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.6 W
Certification	CE, FCC, ISO 9001
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Volume control	Digital
Display diagonal	2.3 \
Display resolution	132 x 64 pixels
Lines quantity	3 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	175 mm
Width	212 mm
Height	54 mm
