Page #18 background imageLoading...
Page #18 background image
BROADSOFT PARTNER CONFIGURATION GUIDE YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 18 OF 150
3 BroadWorks Configuration
This section identifies the required BroadWorks device profile type for the Yealink T4x IP
Phone as well as any other unique BroadWorks configuration required for interoperability
with the T4x IP Phone.
3.1 BroadWorks Device Profile Type Configuration
This section identifies the device profile type to use when deploying the Yealink T4x IP
Phone with BroadWorks.
Create a device profile type for the Yealink T48G IP Phone as shown in the following
example. A separate device profile type should be created for each Yealink T4x IP Phone
model. The settings shown are recommended for use when deploying the Yealink T4x IP
Phone with BroadWorks. For an explanation of the profile parameters, see the
BroadWorks Device Management Configuration Guide [2].
The following device profile type shown provides the Number of Ports (number of SIP
lines) setting for Yealink T4x IP Phone. For other Yealink T4x IP Phone models, create a
new device profile type and set the Number of Ports to match the available number of SIP
lines per model according to the following table.
Model Number of Lines
T40P 3 SIP accounts, 3 line keys
T40G 3 SIP accounts, 3 line keys
T41P 6 SIP accounts, 15 line keys
T41S 6 SIP accounts, 15 line keys
T42G 12 SIP accounts, 15 line keys
T42S 12 SIP accounts, 15 line keys
T46G 16 SIP accounts, 27 line keys
T46S 16 SIP accounts, 27 line keys
T48G 16 SIP accounts, 29 line keys
T48S 16 SIP accounts, 29 line keys
T49G 16 SIP accounts, 29 line keys
