Yealink SIP-T41S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 71 OF 150
Figure 41 Configure Advanced Options
5.2.5.2.2.1.3 Configure Device Management Options
Configure the device profile type Device Management Options as directed in the following
table. These are common settings, which apply to all devices enabled for Device
Management.
Parameters not identified in the following table can usually be left with their default values.
Parameter Value Description
Device Configuration
Tags
Use Default System Tag Set Only
Allow Identity/Device
Profiles to Configure
Custom Tags
Checked Optional
Allow Groups to
Configure Custom
Tags
Checked Optional
Device Access
Protocol
http
Device Access FQDN <BroadWorks-XSP-Cluster-
Address>
Example: xsp.iop1.broadworks.net
If using an Xtended Services
Platform farm, set this to the
Xtended Services Platform cluster
FQDN. Otherwise, set it to the
individual Xtended Services
Platform FQDN or IP address.
Device Access Port <BroadWorks-XSP-Port>
Example: 80
This should be set to “80”.
Device Access
Context Name
dms This does not need to be defined.
BroadWorks defaults to the
system-defined value.
Device Access URI def This defines the directory the
Xtended Services Platform uses to
access the default configuration
files.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
