BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 53 OF 150
The import method should be used if all of the following prerequisites are met:
 The BroadWorks Release is 17.0 or later.
 The device profile type(s) being imported do not already exist on the system. (If either
a previous import or manual configuration was done, then the import fails.)
 There is a DTAF file available for import with a BroadWorks release level that is the
same as or prior to the release to which it is being imported. If the DTAF file is at a
release level later than the release being imported to, then the import can fail.
Otherwise, use the manual method.
For more detailed instructions, see the BroadWorks CPE Kit Usage Guide [8] and the
BroadWorks Device Management Configuration Guide [2].
5.2.2.1 Configuration Method 1: Import
This section identifies the steps necessary to make use of the Device Management import
feature to configure BroadWorks to add the Yealink T4x IP Phone as a Device
Management-enabled device type. Also, see the BroadWorks CPE Kit Usage Guide [8].
Download the Yealink T4x IP Phone CPE kit from BroadSoft Xchange at
xchange.broadsoft.com. Extract the DTAF file(s) from the CPE kit. These are the import
files. Repeat the following steps for each model you wish to import.
1) Log in to BroadWorks as an administrator.
2) Browse to System → Resources → Identity/Device Profile Types and then click
Import.
3) Select Browse to find the extracted DTAF file for the model and then click OK to start
the import.
After the import finishes, complete the following post-import configuration steps:
4) Browse to System → Resources → Identity/Device Profile Types.
5) Perform a search to find the imported Yealink device profile type, Yealink T46G.
6) Browse to the Profile page and change the Device Management Device Access
FQDN to your Xtended Services Platform (Xsp) or Xtended Services Platform cluster
address.

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
