Yealink SIP-T46S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 55 OF 150
5.2.2.2.1 Create or Modify Device Profile Type
This section identifies the BroadWorks device profile type settings relevant to Device
Management for the Yealink T4x IP Phone.
Browse to System → Resources → Identity/Device Profile Types and perform a search to
find the Yealink device profile type(s) created in section 3.1 BroadWorks Device Profile
Type Configuration or add the device profile type for each model using the settings from
section 3.1 BroadWorks Device Profile Type Configuration if they do not exist.
Configure the device profile type Signaling Address Type, Standard and Advanced options
settings to match the settings in section 3.1 BroadWorks Device Profile Type
Configuration.
Configure the device profile type Device Management options as shown in section 5.2.2.1
Configuration Method 1: Import.
The following subsections identify the required settings specific to Device Management.
5.2.2.2.2 Define Device Profile Type Files
This section describes the BroadWorks Device Management configuration necessary to
identify the configuration files and other files that the Yealink T4x IP Phone downloads.
Configuration templates, firmware, and other files the T4x IP Phone uses must be
uploaded to BroadWorks. Download the Yealink T4x IP Phone CPE kit from BroadSoft
Xchange at xchange.broadsoft.com. Extract the configuration files from the Configuration
Files folder of CPE kit. Obtain the firmware files directly from Yealink.
The following table identifies the Yealink T4x IP Phone configuration files distributed with
the firmware version73 CPE kit.
File Name CPE Kit Template File Name File Type Description
System-
level,
Device-
specific,
Static, Time
Zone Alias
Examples
BWMACADDRESS.cfg %BWMACADDRESS%-
T4x.cfg
Device-
specific
This file contains device-specific
parameters that the phone has to
load.
y0000000000xx.cfg
T40P: xx=54
T40G: xx=76
T41P: xx=36
T42G: xx=29
T46G: xx=28
T48G: xx=35
T41S: xx=68
T42S: xx=67
T46S: xx=66
T48S: xx=65
T49G: xx=51
y0000000000xx.cfg
T40P: xx=54
T40G: xx=76
T41P: xx=36
T42G: xx=29
T46G: xx=28
T48G: xx=35
T41S: xx=68
T42S: xx=67
T46S: xx=66
T48S: xx=65
T49G: xx=51
System-
level
This file contains system level
parameters that the phone has to
load.

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
