Yealink T48G Admin Guide

Chapters
How to Find the IP Address
How to Find the MAC Address
How to Set the Configuration Server
How to Restore Factory Default
© Copyright Schmooze Com, 2014
How to Find the IP Address
Quick Steps
1. Press “Menu” to enter the main menu.
2. Press “Status,” which should be the first option.
3. The IP Address will display here.
How to Find the MAC Address
Quick Steps
1. Press “Menu” to enter the main menu.
2. Press “Status,” which should be the first option.
3. The MAC Address will display here.
How to Set the Configuration Server
Quick Steps
1. Enter the IP Address into a local web browser address field.
2. When prompted, enter “admin” as the user name and “admin” as the password.
3. From the home page of the GUI, click on the “Settings” tab at the top.
4. Then click on “Auto Provision” from the options on the left.
5. Lastly, populate the “Server URL” field to your PBX. Generally this would
be an IP Address, such as 10.10.0.1 in our example. Then press the “Confirm” button at the
bottom when you are finished.
How to Restore Factory Default
Quick Steps
1. Press “Menu” to enter the main menu.
2. Press “Advanced,” which should be the last option.
3. Then enter your password. By default this is “admin.”
4. Next use the down arrow to reveal more options on the left.
5. Select the option “Reset to Factory,” choose your Reset Option at the top and then press the
“Reset” button in red.
6. A warning will then show on the screen asking you to “Reset to Factory?” To proceed with this
process, press “OK.”

Yealink T48G Specifications

General

Wi-Fi	No
Display	7" 800 x 480-pixel color touch screen
Network	Dual-port Gigabit Ethernet
PoE	Yes (IEEE 802.3af)
Audio Features	HD voice: HD handset, HD speaker
Voice Codecs	G.722, G.711(A/μ), G.729AB, G.726
Network Features	SIP v1 (RFC2543), v2 (RFC3261)
Bluetooth	Bluetooth via USB Dongle
USB	1 x USB 2.0
Headset	Yes (EHS support)
Expansion Module	Supports up to 6 modules
Local Phonebook	1000 entries
Power Supply	AC 100~240V input, DC 5V/2A output
Supported Languages	English, French, German, Italian, Polish, Portuguese, Russian, Spanish
Operating Temperature	0 ~ 40°C (+32 ~ 104°F)
Humidity	10% to 95%, non-condensing
Dimensions	266 x 226 x 185 mm
