Yealink VC110 - VC110-All-In-One Unit Installation

VC110 All-in-one Unit Installation
Hanging Mode
5
Please choose the following installation mode when the thickness of the TV is between 35-120mm.
TV
4
1
3
2
Adjust the bracket to ensure close adhesion to the back of the TV.
1
Steps:
Make sure the back of the TV is clean, and then adjust the bracket to ensure close adhesion to the back of
3
3
2
Remove the protection of the Velcro.
Put the L-bracket on the
4
the TV with Velcro.
Lock the VC110 all-in-one unit to the L-bracket.
top of the TV.
