NeoGate TG Series Installation Guide
http://www.yeastar.com 7/14
RESET
POWER
LAN
RUN
SIM CARD SLOT
2.2 LED Indicators and Ports
The LED indicators and ports of NeoGate TG Series are straightforward. Take the front panel and rear panel of
NeoGate TG400 and TG1600 as an example.
Figure 2-3 NeoGate TG400 Front Panel
Figure 2-4 NeoGate TG400 Rear Panel
ANTENNA
POWER INLET
