YOKOGAWA 2100A series User Manual

10
SPECIFY THE FOLLOWING WHEN ORDERING
(1) Model and Suffix codes
(2) Full scale value and unit
(3) For suffix code E00,V00,V07,V08 or V11, specifiy rating and full scale value.
Notes :
(1) Scale other than Yokogawa' standard format will be special order.
(2) External multiplierare not supplied.
(3) *: For non- JIS products.
Suffix Codes
-VLA
-VLJ
-VLS
-VMT
-VNL
-VNT
-VPK
-VRX
-VSF
-VSJ
-V00
-V07
-V08
-E00
-E00*
-V01*
-V11
-N
-L
-BL
-BG
-BS
-GS
Descriptions
110 SQUARE Class 1.5
80 SQUARE Class 1.5
0 to 1V
0 to 3V
0 to 5V
0 to 10V
0 to 30V
0 to 50V
0 to 100V
0 to 300V
0 to 500V
0 to 600V
0 to (50mV to 600V),
Optional intermediate rating
0 to (1V to 300V), Current Consumption : 300 microA
Optional full scale value Current Consumption : 500 microA
-a to 0 to +b where a or less 72% × (a+b), a+b=100mV to 600V
For zero-center and similar scale meter
-a to 0 to +b (b=1mA) where a or less 1mA, For zero-center and similar scale meter
0 to 1mA For external multiplier
0 to (10V to 300V) Optional intermediate rating, Voltmeter with VR,
(Current Consumption : 1mA), ±25% Variable
Always "-N"
Lance type pointer (Black), Always "-L"
Munsell N1.5
Munsell 7.5BG4/1.5
Munsell N1.5 with Set pointer (red color)
Munsell 7.5BG4/1.5 with Set pointer (red color)
Model
2101A 30
2181A 00
Rating
Designation of
Frequency Used
Pointer
Cover color and Set pointer
(Current Consumption : 1mA),
Where less than 1V : 2mA

















Suffix Codes
-AHX
-AHE
-VLR
-N
-L
-BL
-BG
-BS
-GS
Descriptions
110 SQUARE Class 1.5
80 SQUARE Class 1.5
10 to 50mA DC, General type (Approx. Internal Resistance : 13 ohm)
4 to 20mA DC, General type (Approx. Internal Resistance : 6 ohm)
1to 5V DC, General type (Approx. Internal Resistance : 4k ohm)
Always "-N"
Lance type pointer (Black), Always "-L"
Munsell N1.5
Munsell 7.5BG4/1.5
Munsell N1.5 with Set pointer (red color)
Munsell 7.5BG4/1.5 with Set pointer (red color)
SPECIFY THE FOLLOWING WHEN ORDERING
(1) Model and Suffix codes
(2) Full scale value and unit
(3) Specifiy TagNO., if necessary.
Notes :
(1) Special unit symbol is available to suppressed meters.
Standard symbol is small letter.
Specify "Capital letter", if necessary.
EX.: M/MIN,TON,etc.
(2) Scale other than Yokogawa' standard format will be special order.
Model
2101A
2181A
Rating 35
36
37
Designation of
Frequency Used
Pointer
Cover color and Set pointer
DC VOLTMETERS
DC AMMETERS ,VOLTMETERS SUPPRESSED METER
