VARMETERS
2106A/2186A
Model Suffi x Codes Descriptions
2106A 31 Single phase 2-wire
110 SQUARE Class 1.5
2106A 33 3-phase 3-wire (Balanced)
2106A 35 3-phase 3-wire (Unbalanced)
2106A 34 3-phase 4-wire (Balanced)
2106A 36 3-phase 4-wire (Unbalanced)
2186A 31 Single phase 2-wire
80 SQUARE
With external
transducer
Class 1.5
2186A 33 3-phase 3-wire (Balanced)
2186A 35 3-phase 3-wire (Unbalanced)
2186A 34 3-phase 4-wire (Balanced)
2186A 36 3-phase 4-wire (Unbalanced)
Rating
-M13 110V/1A
Single phase 2-wire
(Zero-center) -M14 110V/5A
-M15 220V/1A
-M16 220V/5A
-M13 110V/1A
3-phase 3-wire
-M14 110V/5A
-M15 220V/1A
-M16 220V/5A
-M11
110/
√
_
3
V 1A
3-phase 4-wire For 21
6A36
-M12
110/
√
_
3
V 5A
-M13 110V/1A
3-phase 4-wire For 21
6A34
-M14 110V/5A
-M15 220V/1A
-M16 220V/5A
-M17
220/
√
_
3
V 1A
3-phase 4-wire For 21
6A36
-M18
220/
√
_
3
V 5A
-M51 100V/1A
Semi-standard meters
For 21
6A31,33,35
-M52 100V/5A
-M53 115V/1A
-M54 115V/5A
-M55 120V/1A
-M56 120V/5A
-M61 200V/1A
-M62 200V/5A
-M63 230V/1A
-M64 230V/5A
-M65 240V/1A
-M66 240V/5A
(Single
defl ecting or
Unbalanced
scale)
-P13 110V/1A
Single phase 2-wire
-P14 110V/5A
-P15 220V/1A
-P16 220V/5A
-P13 110V/1A
3-phase 3-wire
For 21
6A34
-P14 110V/5A
-P15 220V/1A
-P16 220V/5A
-P53 115V/1A
-P54 115V/5A
-P11
110V/
√
_
3
V 1A
3-phase 4-wire
For 21
6A36
-P12
110V/
√
_
3
V 5A
-P17
220V/
√
_
3
V 1A
-P18
220V/
√
_
3
V 5A
Designation of
Frequency Used
-N 50/60Hz Common For 21
6A33,34
-A 50Hz
For 21
6A31,35,36
-B 60Hz
-C 400Hz
Pointer
-L Lance type pointer (Black), Always "-L"
Cover color and Set pointer
-BL Munsell N1.5
-BG Munsell 7.5BG4/1.5
-BS Munsell N1.5 with Set pointer (red color)
-GS Munsell 7.5BG4/1.5 with Set pointer (red color)
SPECIFY THE FOLLOWING WHEN ORDERING
(1) Model and Suffi x codes
(2) Full scale value and unit
(3) In case of using external CT/or VT, calculate the possible full scale value form
the following page and be sure that is within the range shown avove.
(4) VT ratio and CT ratio
Notes :
VT and CT are not supplied.
[Scale scope]
(1) Zero-center meter:
LEAD a to 0 to LAG b var where a=b
(2) Single defl ecting meter:
0 to LEAD var or 0 to LAG var
(3) Unbalanced scale meter:
LEAD a to 0 to LAG b var where a less than b
