Suffix Codes
-ALA
-ALJ
-ALS
-AMT
-ANL
-A00
-A41
-A42
-A21
-A22
-A25
-A26
-A32
-A34
-A35
-A36
-A52
-A55
-A43
-A44
-A45
-A46
-A47
-A48
-VNT
-VPK
-VPZ
-VRX
-VSJ
-V00
-V12
-V13
-V20
-V21
-N
-C
-L
-BL
-BG
-BS
-GS
Descriptions
110 SQUARE Class 1.5
80 SQUARE Class 1.5
0 to1A
0 to 3A
0 to 5A
0 to 10A
0 to 30A
0 to (1A to 30A) Optional intermediate rating
0 to 1A
0 to 5A
0 to 0.5 to 1 A
0 to 1 to 2 A
0 to 5 to 10A
0 to 10 to 20 A
0 to 1 to 3 A
0 to 3 to 9A
0 to 5 to 15 A
0 to 10 to 30A
0 to 1 to 5A
0 to 5 to 25A
0 to 1 to 2A
0 to 5 to 10A
0 to 1 to 3A
0 to 5 to 15A
0 to 1 to 5A
0 to 5 to 25A
0 to 50V (Power Consumption : 0.1VA)
0 to 100V (Power Consumption : 0.6VA)
0 to 150V (Power Consumption : 0.9VA)
0 to 300V (Power Consumption : 1.8VA)
0 to 600V (Power Consumption : 1.2VA)
0 to (50V to 600V), Optional intermediate rating
0 to 150V For use with external VT (Power Consumption : 0.9VA)
0 to 150/ √3V For use with external VT (Power Consumption : 0.2VA)
Expanded scale 70 to 130V (Power Consumption : 0.5VA)
Expanded scale 140 to 260V (Power Consumption : 1.0VA)
50/60Hz Common
400Hz
Lance type pointer (Black), Always "-L"
Munsell N1.5
Munsell 7.5BG4/1.5
Munsell N1.5 with Set pointer (red color)
Munsell 7.5BG4/1.5 with Set pointer (red color)
SPECIFY THE FOLLOWING WHEN ORDERING
(1) Model and Suffix codes
(2) Full scale value and unit
(3) For suffix code A00 or V00, specifiy rating and full scale value.
(4) VT ratio and CT ratio
Notes :
VT and CT are not supplied.
Model
2102A 30
2182A 00
Rating
Designation of
Frequency Used
Pointer
Cover color and Set pointer
(For external CT)
Two-fold extended
Three-fold extended
Five-fold extended
Two-fold extended (For external CT)
Three-fold extended (For external CT)
Five-fold extended (For external CT)
(Power
Consumption :
0.4VA)
AC AMMETERS, VOLTMETERS
RMS rectifier type
2102A/2182A
