YOKOGAWA 2100A series

29
EXTERNAL SHUNT
2215, 2216, 2217
Model Rating
2215
01
50 mV
1 A
02 1.5 A
03 2 A
04 3 A
05 5 A
06 7.5 A
07 10 A
08 15 A
09 20 A
10 30 A
11 50 A
12 75 A
13 100 A
14 150 A
15 200 A
16 300 A
2216
01
50 mV
500 A
02 750 A
03 1000 A
2217
01
50 mV
1500 A
02 2000 A
03 3000 A
04 5000 A
Class: Class 0.2 of rated value
Rated voltage drop: 50 mV
EXTERNAL MULTIPLIER
2224, 2225, 2226, 2228
Model Rating
Current
Consumption
2224
01 50 V
1 mA
02 75 V
03 100 V
04 150 V
05 300 V
06 500 V
07 750V
2225 00 1 kV
2226
01 1.5 kV
02 2 kV
03 3 kV
2228
01 5 kV
02 7.5 kV
Accuracy: ±0.5% of rated value
Measuring method: 2224...2 terminal type
2225, 2226, 2228...3 terminal type
EXTERNAL VT
Model 2267 2268
Rated Burden 15 VA 50 VA
Primary
Secondary ——
220 V
110 V
2267 01 —
440 V 2267 02 —
1100 V 2267 03 —
2200 V 2267 04 —
3300 V 2267 05 2268 01
6600 V — 2268 02
Class: Equivalent to JIS C1731 Class 1.0
Structure: Epoxy mold type
EXTERNAL CT
2255
Model Primary Secondary
2255
01 10 A
5 A
(15 VA max.)
02 15 A
03 20 A
04 30 A
05 50 A
06 75 A
07 100 A
08 150 A
09 200 A
10 250 A
11 300 A
12 500 A
Class: Equivalent to JIS C1731 Class 1.0
Structure: Epoxy model type
Dielectric Strength: less than 3450V
ACCESSORIES
OTHER
Shunt lead: 219930-24
110
175
45
150±
0.4
30
5.5 dia.
12 dia. spot
facing
M5
M6
17.5
6.5
14.5
35.5
110
175
150±
0.4
5.5 dia.
12 dia.
50
M5
* M6
* 100 to 300 A are M8
6.5
14.5
H
10 to 100 A 39.5
150 to 300 A 54.5
500 A 50
750 A 64
130
130
230
230
50
60
1,000 A 6417027084
30
A
M5 M12
6.5
WH
P32
2,000 A 12358150
3,000 A 205311770
110
1,500 A 123574—92
120
M5 M12 14 dia.
32
6
700
540
50
90
200
M5 M12 14 dia.
270
17032 32
50
W
50
50
53
110
136
66
66
6
D
H C
*Dashed line is
for 1,500 A
Q
2215 (1 to 7.5 A) 2215 (10 to 300 A) 2216 (500 to 1000 A)
2217 (1,500 to 3,000 A) 2217 (5,000 A)
Rating H
Rating HPAW
Rating DCHQW
(unit: mm)
DIMENSIONS FOR ACCESSORIES
