<1. Introduction>
1
IM 01E24A01-01EN4th Edition: July 2019 (KP)
All Rights Reserved, Copyright © 2016, Yokogawa Electric Corporation
1. Introduction
This manual provides the basic guidelines for installation,
wiring procedures and basic operation of ADMAG TI
(Total Insight) Series AXW magnetic owmeters (size: 25
to 400 mm (1 to 16 in.)) with BRAIN, HART, Modbus and
F
OUNDATION Fieldbus protocol.
For the items which are not covered in this manual,
read the applicable user’s manuals and general
specications as listed in Table 1.1. These documents
can be downloaded from the website of YOKOGAWA. To
ensure correct use of the product, read these manuals
thoroughly and fully understand how to operate the
product before operating it. For method of checking the
model and specications, read Chapter 2 and general
specications as listed in Table 1.1.
Website address: http://www.yokogawa.com/d/doc/
These manuals can be downloaded from the website
of YOKOGAWA or purchased from the YOKOGAWA
representatives.
Table 1.1 Manual and General Specications List
Model Document Title Document No.
AXW###
AXW4A
AXG1A
AX01C
ADMAG TI Series
AXG###, AXW###, AXG4A, AXW4A,
AXG1A
Magnetic Flowmeter
Read Me First (Optional Code EC)
IM 01E21A11-01EN
ADMAG TI Series
AXG###, AXW###, AXG4A,
AXW4A, AXG1A
Magnetic Flowmeter
Read Me First
IM 01E21A21-01Z1
ADMAG TI Series
AXG/AXW Magnetic Flowmeter
Safety Manual
IM 01E21A21-02EN
ADMAG TI Series
AXW Magnetic Flowmeter
[Size: 25 to 400 mm (1 to 16 in.)]
Installation Manual
IM 01E24A01-01EN
(this manual)
ADMAG TI Series
AXW Magnetic Flowmeter
[Size: 25 to 1800 mm (1 to 72 in.)]
Maintenance Manual
IM 01E24A01-02EN
ADMAG TI Series
AXW Magnetic Flowmeter
BRAIN Communication Type
IM 01E24A02-01EN
ADMAG TI Series
AXW Magnetic Flowmeter
HART Communication Type
IM 01E24A02-02EN
ADMAG TI Series
AXG, AXW Magnetic Flowmeter
Modbus Communication Type
IM 01E21A02-05EN
ADMAG TI Series
AXG/AXW Magnetic Flowmeter
F
OUNDATION Fieldbus
Communication Type
IM01E21A02-03EN
ADMAG TI Series
AXG1A Magnetic Flowmeter
BRAIN Communication Type
IM 01E22C02-01EN
ADMAG TI Series
AXG1A Magnetic Flowmeter
HART Communication Type
IM 01E22C02-02EN
Model Document Title Document No.
AXW###
AXW4A
AXG1A
AX01C
ADMAG TI Series
AXW Magnetic Flowmeter
[Size: 25 to 400 mm (1 to 16 in.)]
General Specications
GS 01E24A01-01EN
ADMAG TI Series
AXG1A Magnetic Flowmeter
Remote Transmitter
General Specications
GS 01E22C01-01EN
AXFA11G
AXF Series
Magnetic Flowmeter
Read Me First
IM 01E20A21-01Z1
AXFA11G Remote Converter
[Hardware Edition/Software Edition]
IM 01E20C01-01E
AXFA11G Remote Converter
General Specications
GS 01E20C01-01E
AXW###
ADMAG TI Series
AXG/AXW Magnetic Flowmeter
ATEX Explosion Protection Type
IM 01E21A03-02EN
ADMAG TI Series
AXG/AXW Magnetic Flowmeter
IECEx Explosion Protection Type
IM 01E21A03-03EN
NOTE
When describing the model name like AXW### in this
manual, “###” means any of the following.
025, 032, 040, 050, 065, 080, 100, 125, 150, 200, 250,
300, 350, 400
 Precautions Related to the Protection,
Safety, and Alteration of the Product
The following safety symbol marks are used in this
manual and product.
WARNING
A WARNING sign denotes a hazard. It calls attention to
procedure, practice, condition or the like, which, if not
correctly performed or adhered to, could result in injury
or death of personnel.
CAUTION
A CAUTION sign denotes a hazard. It calls attention
to procedure, practice, condition or the like, which, if
not correctly performed or adhered to, could result in
damage to or destruction of part or all of the product.
IMPORTANT
An IMPORTANT sign denotes that attention is required
to avoid damage to the product or system failure.
1
Introduction
