YOKOGAWA DLM4058 User Manual

App-5
IM DLM4038-03EN
1
2
3
4
5
6
App
Index
Appendix
When the Record Length Is 6.25 M points
(This record length can be selected when there is no memory option or on DLM4000s
with the /M1 or /M3 option)
IntP: Interpolation Mode
Rep: Repetitive Sampling Mode
Settings
Time/div
When High Resolution mode is off When High Resolution mode is on
1
When Interleave mode is off When Interleave mode is on When Interleave mode is off When Interleave mode is on
Realtime IntP/Rep
2
Realtime IntP/Rep
2
Realtime IntP/Rep Realtime IntP/Rep
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
500 s 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M 1.25 k 6.25 M
200 s 3.125 k 6.25 M 3.125 k 6.25 M 3.125 k 6.25 M 3.125 k 6.25 M 3.125 k 6.25 M 3.125 k 6.25 M 3.125 k 6.25 M 3.125 k 6.25 M
100 s 6.25 k 6.25 M 6.25 k 6.25 M 6.25 k 6.25 M 6.25 k 6.25 M 6.25 k 6.25 M 6.25 k 6.25 M 6.25 k 6.25 M 6.25 k 6.25 M
50 s 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M
20 s 31.25 k 6.25 M 31.25 k 6.25 M 31.25 k 6.25 M 31.25 k 6.25 M 31.25 k 6.25 M 31.25 k 6.25 M 31.25 k 6.25 M 31.25 k 6.25 M
10 s 62.5 k 6.25 M 62.5 k 6.25 M 62.5 k 6.25 M 62.5 k 6.25 M 62.5 k 6.25 M 62.5 k 6.25 M 62.5 k 6.25 M 62.5 k 6.25 M
5 s 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M 125 k 6.25 M
2 s 312.5 k 6.25 M 312.5 k 6.25 M 312.5 k 6.25 M 312.5 k 6.25 M 312.5 k 6.25 M 312.5 k 6.25 M 312.5 k 6.25 M 312.5 k 6.25 M
1 s 625 k 6.25 M 625 k 6.25 M 625 k 6.25 M 625 k 6.25 M 625 k 6.25 M 625 k 6.25 M 625 k 6.25 M 625 k 6.25 M
500 ms 1.25 M 6.25 M 1.25 M 6.25 M 1.25 M 6.25 M 1.25 M 6.25 M 1.25 M 6.25 M 1.25 M 6.25 M 1.25 M 6.25 M 1.25 M 6.25 M
200 ms 3.125 M 6.25 M 3.125 M 6.25 M 3.125 M 6.25 M 3.125 M 6.25 M 3.125 M 6.25 M 3.125 M 6.25 M 3.125 M 6.25 M 3.125 M 6.25 M
100 ms 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M 6.25 M
50 ms 12.5 M 6.25 M 12.5 M 6.25 M 12.5 M 6.25 M 12.5 M 6.25 M 12.5 M 6.25 M 12.5 M 6.25 M 12.5 M 6.25 M 12.5 M 6.25 M
20 ms 31.25 M 6.25 M 31.25 M 6.25 M 31.25 M 6.25 M 31.25 M 6.25 M 31.25 M 6.25 M 31.25 M 6.25 M 31.25 M 6.25 M 31.25 M 6.25 M
10 ms 62.5 M 6.25 M 62.5 M 6.25 M 62.5 M 6.25 M 62.5 M 6.25 M 62.5 M 6.25 M 62.5 M 6.25 M 62.5 M 6.25 M 62.5 M 6.25 M
5 ms 125 M 6.25 M 125 M 6.25 M 125 M 6.25 M 125 M 6.25 M 125 M 6.25 M 125 M 6.25 M 125 M 6.25 M 125 M 6.25 M
2 ms 312.5 M 6.25 M 312.5 M 6.25 M 312.5 M 6.25 M 312.5 M 6.25 M 312.5 M 6.25 M 312.5 M 6.25 M 312.5 M 6.25 M 312.5 M 6.25 M
1 ms 625 M 6.25 M 625 M 6.25 M 625 M 6.25 M 625 M 6.25 M 625 M 6.25 M 625 M 6.25 M 625 M 6.25 M 625 M 6.25 M
500 μs 1.25 G 6.25 M 1.25 G 6.25 M 1.25 G 6.25 M 1.25 G 6.25 M 625 M 3.125 M 1.25 G 6.25 M 1.25 G 6.25 M 1.25 G 6.25 M
200 μs 1.25 G 2.5 M 3.125 G 6.25 M 2.5 G
5 M 3.125 G 6.25 M
625 M 1.25 M 3.125 G 6.25 M 1.25 G 2.5 M 3.125 G 6.25 M
100 μs 1.25 G 1.25 M 6.25 G 6.25 M 2.5 G 2.5 M 6.25 G 6.25 M 625 M 625 k 6.25 G 6.25 M 1.25 G 1.25 M 6.25 G 6.25 M
50 μs 1.25 G 625 k 12.5 G 6.25 M 2.5 G 1.25 M 12.5 G 6.25 M 625 M 312.5 k 12.5 G 6.25 M 1.25 G 625 k 12.5 G 6.25 M
20 μs 1.25 G 250 k 31.25 G 6.25 M 2.5 G 500 k 31.25 G 6.25 M 625 M 125 k 31.25 G 6.25 M 1.25 G 250 k 31.25 G 6.25 M
10 μs 1.25 G 125 k 62.5 G 6.25 M 2.5 G 250 k 62.5 G 6.25 M 625 M 62.5 k 62.5 G 6.25 M 1.25 G 125 k 62.5 G 6.25 M
5 μs 1.25 G 62.5 k 125 G 6.25 M 2.5 G 125 k 125 G 6.25 M 625 M 31.25 k 125 G 6.25 M 1.25 G 62.5 k 125 G 6.25 M
2 μs 1.25 G 25 k 125 G 2.5 M 2.5 G 50 k 125 G 2.5 M 625 M 12.5 k 125 G 2.5 M 1.25 G 25 k 125 G 2.5 M
1 μs 1.25 G 12.5 k 125 G 1.25 M 2.5 G 25 k 125 G 1.25 M 625 M 6.25 k 125 G 1.25 M 1.25 G 12.5 k 125 G 1.25 M
500 ns 1.25 G 6.25 k 125 G 625 k 2.5 G 12.5 k 125 G 625 k 625 M 3.125 k 125 G 625 k 1.25 G 6.25 k 125 G 625 k
200 ns 1.25 G 2.5 k 125 G 250 k 2.5 G 5 k 125 G 250 k 625 M 1.25 k 125 G 250 k 1.25 G 2.5 k 125 G 250 k
100 ns 1.25 G 1.25 k 125 G 125 k 2.5 G 2.5 k 125 G 125 k 625 M 625 125 G 125 k 1.25 G 1.25 k 125 G 125 k
50 ns 1.25 G 625 125 G 62.5 k 2.5 G 1.25 k 125 G 62.5 k 625 M 312.5 125 G 62.5 k 1.25 G 625 125 G 62.5 k
20 ns 1.25 G 250 125 G 25 k 2.5 G 500 125 G 25 k 625 M 125 125 G 25 k 1.25 G 250 125 G 25 k
10 ns 1.25 G 125 125 G 12.5 k 2.5 G 250 125 G 12.5 k 625 M 62.5 125 G 12.5 k 1.25 G 125 125 G 12.5 k
5 ns 1.25 G 62.5 125 G 6.25 k 2.5 G 125 125 G 6.25 k 625 M 31.25 125 G 6.25 k 1.25 G 62.5 125 G 6.25 k
2 ns 1.25 G 25 125 G 2.5 k 2.5 G 50 125 G 2.5 k 625 M 12.5 125 G 2.5 k 1.25 G 25 125 G 2.5 k
1 ns 1.25 G 12.5 125 G 1.25 k 2.5 G 25 125 G 1.25 k 625 M 6.25 125 G 1.25 k 1.25 G 12.5 125 G 1.25 k
Values outside of the thick borders have been calculated in real-time sampling mode.
If there is no memory option, acquisition with this record length is performed in single mode.
1 If there is no memory option, high resolution mode cannot be used with this record length.
2 If there is no memory option, interpolation mode and repetitive sampling mode cannot be used with this record length.
: Roll Mode
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
