YOKOGAWA DLM4058 User Manual

6-18
IM DLM4038-03EN
6.10 Computer Interface
GP-IB (/C1 Option)
Item Specifications
Electrical and mechanical
specifications
Complies with IEEE St’d 488-1978 (JIS C 1901-1987)
Functional specifications SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT0, C0
Protocol Complies with IEEE St’d 488.2-1992
Code ISO (ASCII) codes
Mode Addressable mode
Addresses Talker and listener addresses can be specified from 0 to 30.
Clearing remote mode Remote mode can be cleared with the SHIFT+CLEAR TRACE key (except during Local Lockout).
USB for PC Connection
Item Specifications
Connector type USB type B (receptacle)
Electrical and mechanical
specifications
USB Rev. 2.0 compliant
Supported transfer mode FS (Full Speed; 12 Mbps), HS (High Speed; 480 Mbps)
Ports 1
Supported protocols Functions as a device that conforms to one of the following two protocols.
USBTMC-USB488(USB Test and Measurement Class Ver. 1.0)*
GP-IB commands can be used through USB.
Mass Storage Class Ver.1.1
Only reading is possible from the DLM4000 internal memory through PC access.
(Operations, such as formatting, are not possible.)
PC system requirements A PC running the English or Japanese version of Windows 7 (32bit, 64bit), Windows 8 (32bit, 64bit),
Windows 8.1 (32bit, 64bit), or Windows 10 (32bit, 64bit)
* A separate driver is required.
Ethernet Interface
Item Specifications
Connector type RJ-45
Ports 1
Electrical and mechanical
specifications
IEEE 802.3 compliant
Transmission system Ethernet (1000BASE-T, 100BASE-TX, 10BASE-T)
Communication protocol TCP/IP
Supported services Server: FTP, HTTP (Web), and VXI-11
Client: FTP (Net Drive), SMTP (Mail), SNTP, LPR (Net Print), DHCP, and DNS
PC system requirements A PC running the English or Japanese version of Windows 7 (32bit, 64bit), Windows 8 (32bit, 64bit),
Windows 8.1 (32bit, 64bit), or Windows 10 (32bit, 64bit)
