6-8
IM DLM4038-03EN
6.3 Time Axis
Item Specifications
Selectable time scale range 1 ns/div to 500 s/div
Timebase accuracy* ±0.002%
Time measurement
accuracy*
±(0.002% + 50 ps + 1 sample period)
* Values measured under standard operating conditions (see section 6.11 for details) after a 30-minute warm-up.
6.4 Display
Item Specifications
Display 12.1-inch (31.4 cm) color TFT LCD*
Display screen size 245.76 mm (width) × 184.32 mm (height)
Resolution of the entire
screen
1024 × 768 (XGA)
Resolution of the waveform
display
1000 × 640
* The LCD may include a few defective pixels (within 4 ppm over the total number of pixels including RGB).
The LCD may contain some pixels that are always illuminated or that never illuminate. Please be aware that these are not
defects.
