Common Operations
3-3
IM DLM4038-03EN
3
3.2 Entering Values and Strings
Entering Values
Using Dedicated Knobs
You can use the following dedicated knobs to enter values directly.
• POSITION knobs (VERTICAL)
• POSITION knobs (HORIZONTAL)
• SCALE knob (VERTICAL)
• TIME/DIV knob
• LEVEL knob (TRIGGER)
• ZOOM magnification knob
Using the Jog Shuttle
Select the appropriate item using the soft keys, and change the value using the jog shuttle and the
SET key. This manual sometimes describes this operation simply as “using the jog shuttle.”
Note
Some items that you can set using the jog shuttle are reset to their default values when you press the RESET
key.
To Next Page
