Item
Model/
Part No.
Min.
Q’ty
Specifications Manual No.
100:1 high-voltage passive probe
701944 1
DC to 400 MHz bandwidth, 1000 Vrms,
1.2 m in length
IM 701944-01E
701945 1
DC to 250 MHz bandwidth, 1000 Vrms,
3m in length
FET probe* 700939 1 DC to 900 MHz bandwidth, 2.5 MΩ, 1.8 pF IM 700939-01E
Differential probe*
700924 1
DC to 100 MHz bandwidth,
±1400 V maximum
IM 700924-01E
700925 1
DC to 15 MHz bandwidth,
±500 V maximum
IM 700925-01E
701920 1
DC to 500 MHz bandwidth,
±30 V maximum (common-mode input)
IM 701920-01E
701921 1
DC to 100 MHz bandwidth,
±700 V maximum
IM 701921-01E
701922 1
DC to 200 MHz bandwidth,
±60V maximum (common-mode input)
IM 701922-01E
701926 1
DC to 50 MHz bandwidth,
7000 V maximum (common-mode input)
IM 701926-01E
Current probe*
701917 1 DC to 50 MHz bandwidth, 5 Arms IM 701917-01EN
701918 1 DC to 120 MHz bandwidth, 5 Arms IM 701917-01EN
701930 1 DC to 10 MHz bandwidth, 150 Arms IM 701930-01E
701931 1 DC to 2 MHz bandwidth, 500 Arms IM 701931-01E
701932 1 DC to 100 MHz bandwidth, 30 Arms IM 701932-01E
701933 1 DC to 50 MHz bandwidth, 30 Arms IM 701933-01E
PBL500 5 GHz low capacitance
probe
701974 1 — IM 701974-01E
Deskew signal source 701936 1
Approx. 0 to 5 V, approx. 0 to 100 mA,
approx. 0 to 1 A, approx. 15 kHz
IM 701936-01EN
Mini clip adapter 700971 1 set For 701939 passive probes —
BNC adapter 700972 1 — —
Logic probe accessory kit 701909 1 set For the 701989 —
Probe stand 701919 1 — IM 701919-01E
PCB adapter 366945 1 set For 701939 passive probes —
Solder-in adapter 366946 1 set For 701939 passive probes —
GO/NO-GO cable 366973 1 — —
Soft carrying case 701968 1
For the DLM4000 series,
shoulder type, three pockets
—
Rack mount kit
701969-E 1 EIA standard IM 701969-02EN
701969-J 1 JIS standard IM 701969-01EN
Optional accessories (sold separately) are not covered by warranty of this instrument.
* Used by connecting to a probe power terminal (/P8 option) or a probe power supply (701934; sold
separately).
Spare Parts (Sold Separately)
The spare parts below are available for purchase separately. Check that all contents are present and
undamaged.
For information about ordering spare parts, contact your nearest YOKOGAWA dealer.
Name Part No. Minimum Q’ty Note
Printer roll paper B9988AE 10 Thermo-sensitive paper, 111 mm × 10 m
Checking the Contents of the Package
