5. PARAMETER SETUP
(4) Item D (AUX SETUP)
These items are for Auxiliary setup.
A value in “( )” is the data corresponding to indicator.
[D10:LOW CUT] Low-cut flowrate
NOTE
For D10 setting, be sure to set “NOMINAL SIZE”
in E10 firstly.
Set to noise elimination or zero flow in the low flowrate (or
low frequency) range. The settable range for low cut flowrate
is more than half-minimum flowrate.
NOTE
In case that D10: LOW CUT and item H (ADJUST)
are necessary to set, change all appropriate
parameters of item H before setting D10.
[D20:TEMP UNIT] Fluid temperature unit at
operating conditions
Select temperature unit at operating condition from
“degC (0), degF (1)”.
[D21:TEMP f] Fluid temperature at operating
conditions
Set fluid temperature at operating condition.
Range is -196 to 450°C
[D25:DENSITY UNIT] Density Unit of Flow
measurement
Select the unit of density from kg/m
3
(0), lb(1), lb/USgal(2),
lb/UKgal(3).
[D26:DENSITY f] Density at normal operation
conditions
Set the density value of the fluid at operating condition for
mass flow unit
[D30:OUT LIMIT] Limit value of output and
indication
Set limit value of output from 100.0% to 110.0%
[D35:BURN OUT] Indication of the output
direction at burn out
This is indication of the output direction at burn out. Refer to
“6.1.6 Burn out” when the output direction can be changed.
[D40:SPECIAL UNIT] Change to special
flowrate unit
Select the availability of changing to special flowrate Unit
from “No(0)” or “Yes(1)”
[D41:BASE UNIT] Indication of the special
flowrate unit
Indication of the basic flowrate unit when item D40 is
“Yes(1)”
[D42:USER'S UNIT] Free unit for users
Set in up to 8 alphanumeric characters when item D40 is
“Yes(1)”
