YOKOGAWA DY080 User Manual

4-4
IM 01F06A00-01E
4. BASIC OPERATING PROCEDURES
4.3.1 Change the Display Mode from % Display to Engineering Unit
The display mode can be changed referring 5.3 parameter list.
SET
INCSHIFT
SET
INCSHIFT
SET
INCSHIFT
SET
INCSHIFT
SET
INCSHIFT
SET
INCSHIFT
SET
INCSHIFT
SET
INCSHIFT
SET
INCSHIFT
F040302.EPS
Indication of %
display.
Enter the setting
mode.
Enter the parameter
item.
Indicate “ 30 ”
referring 5.3
parameter list.
Enter the data
input item.
Indicate “ 01 ” of
engineering unit
referring 5.3
parameter list.
Ensure the setting
data.
Finish the setting.
Return to display
mode.
Press “ SET ” key.
Press “ SHIFT ” key.
Press “ INC ” key any time.
Press “ SET ” key.
Press “ INC ” key.
Press “ SET ” key.
Press “ SET ” key.
Press “ SET ” and “ SHIFT ” key.
IMPORTANT
After setting a parameter, keep the power on for at
least 30 seconds.
If the power of flowmeter is turned off, a parameter
setting is released.
