YOKOGAWA DY080 User Manual

9-13
IM 01F06A00-01E
9. GENERAL DESCRIPTION
KN1
CENELEC ATEX
(KEMA)
Canadian
Standards
Association
(CSA)
Code
CSA Explosion proof Approval
Applicable Standard: C22.1-98, C22.2 No.0-M1991, C22.2 No.0.4-04, C22.2 No. 0.5-1982,
C22.2 No. 25-1966, C22.2 No. 30-M1986, C22.2 No. 94-M1991,
C22.2 No. 142-M1987, C22.2 No. 61010-1-04, ANSI/ISA-12.27.01-2003
Type of Protection : Explosionproof for Class I, Groups B, C and D;
Class II, Groups E, F, and G; Class III.
For Class I, Division 2 location:
"FACTORY SEALED, CONDUIT SEAL NOT REQUIRED"
Enclosure : Type 4X
Temperature Code : T6...T1 (Integral Type Flowmeter and Remote Type Flowmeter)
T6 (Remote Type Converter)
Amb.Temp. : –29 to +60°C (Integral Type Flowmeter and Remote Type Flowmeter)
–40 to +60°C (Remote Type Converter)
Process temp. : T6;85°C, T5;100°C, T4;135°C, T3;200°C, T2;300°C, T1; 450°C
Maximum working Pressure : 16MPa (DY015 to DY200)
5MPa (DY250 and DY300)
Electrical Connection: ANSI 1/2 female (Special)
CSA Explosion proof Approval
• The approval specification is the same with /CF1.
• Process Sealing Certification
Dual Seal Certified by CSA to the requirement of ANSI/ISA 12.27.01
No additional sealing required
CSA Intrinsically safe Approval (Note 2)
Applicable Standard: C22.2 No. 0.4-2004, C22.2 No. 157-M1987, C22.2 No. 213-M1987, C22.2 No. 1010.1-92,
CAN/CSA-E60079-0:02, CAN/CSA-E60079-11:02, CAN/CSA-E60079-15:02 ANSI/ISA-12.27.01-2003
Type of Protection : Ex ia IIC T4...T1 and Ex nC IIC T4...T1(Integral Type Flowmeter and Remote Type
Flowmeter)
Ex ia IIC T4 and Ex nC IIC T4(Remote Type Converter)
Temperature Class.: T4;135°C, T3;200°C, T2;300°C, T1;450°C (Integral Type Flowmeter and Remote
Type Flowmeter)
Amb. Temp. : –29 to +60°C (Integral Type Flowmeter and Remote Type Flowmeter)
–40 to +60°C (Remote Type Converter)
Amb. Hum. : 0 to 100%RH (No condensation)
Degree of Protection of Enclosure:IP67
Electrical Parameters:Ui=30Vdc, Ii=165mAdc, Pi=0.9W, Ci=12nF, Li=0.15mH.
Intrinsically Safe for Class I, II, III, DIV.1, Groups A, B, C, D, E, F and G
Non-incendive for Class I, II, DIV.2, Groups A, B, C, D, E, F and G, ClassIII, DIV.1.
Temperature Code : T4;135°C, T3; 200°C, T2; 300°C, T1; 450°C (Integral Type Flowmeter and Remote
Type Flowmeter)
T4;135°C (Remote Type converter)
Enclosure : Type 4X
Electrical Parameter:Vmax =30Vdc, Imax =165mAdc, Pmax = 0.9W, Ci =12nF, Li = 0.15mH.
Maximum working Pressure : 16MPa (DY015 to DY200)
5MPa (DY250 and DY300)
Electrical Connection: ANSI 1/2 NPT female
CSA Intrinsically safe Approval
• The approval specification is the same with /CS1.
• Process Sealing Certification
Dual Seal Certified by CSA to the requirement of ANSI/ISA 12.27.01
No additional sealing required
T090408.EPS
CF1
CF11
CS1
CS11
CENELEC ATEX (KEMA) Type n Approval
Applicable Standard: EN60079-15: 2005, IEC60079-0: 2004, IEC60079-11: 1999, EN60529: 1991
Type of Protection : EEx nL IIC T4...T1 (Integral Type Flowmeter and Remote Type Flowmeter)
EEx nL IIC T4 (Remote Type Converter)
Group : II
Category : 3G
Degree of Protection of Enclosure: IP67
Maximum Working Pressure : 16MPa (DY015 to DY200)
5MPa (DY250 and DY300)
Ambient Temperature: -29 to +60°C (Integral Type Flowmeter)
: -29 to +80°C (Remote Type Flowmeter)
: -40 to +60°C (Remote Type Converter)
Process Temp.: T4; 135°C, T3; 200°C, T2(*); 300°C, T1(*); 450°C
(*: Use /HT version above 250°C)
Electrical data:
Supply and Output Circuit (SUPPLY + and -, PULSE + and -);
Maximum Input Voltage Ui: 30 V
Internal Capacitance Ci: 6nF
Internal Inductance Li: 0.15mH
Maximum Capacitance of Cable :160nF
Electrical Connection : ANSI 1/2 NPT female, ISO M20 X 1.5 female.
